A few questions about your fuse panel wiring. I see you have a wire noted as Pin 51 ECU. My OBD1 ABA harness does not have a pin 51 populated at the ECU.
Also I see you have wiring labelled as AC high idle. What does this go to? I have a green two pin connector with a blue and yellow on one pin and this rings out to ECU pin 39. Is this the AC high idle input?
